Versatile Data Acquisition Systems

A data acquisition system (DAS) is hardware and software that collects, conditions, digitizes, and processes signals from sensors or RF sources for analysis and storage. In flight test applications, a DAS such as Lumistar's LS-28-DRSM or LS-68 Series receives telemetry signals, demodulates PCM data streams, synchronizes frames, and distributes data in real time over Ethernet or archives it for post-mission review.

Lumistar systems support RF reception from 200 MHz to 6 GHz, covering Lower and Upper L-Band, S-Band, NATO E-Band, C-Band, and P-Band. The LS-29-R2 and LS-28-DRSM also accept 70 MHz IF input, providing broad compatibility with existing antenna and downlink infrastructure used in aerospace and defense test ranges.

Lumistar data acquisition systems support a wide range of formats including PCM/FM, SOQPSK-TG, BPSK, QPSK, OQPSK, AQPSK, AUQPSK, UQPSK, Multi-H CPM, PCM/PM, and Analog Video FM (NTSC/PAL). Future modulation formats can be added via software and firmware upgrades, protecting your investment as IRIG standards evolve.

Yes. The LS-28-DRSM is available in an IP-67-rated portable lunchbox form factor and a compact modular brick, both engineered for mobile, airborne, and shipboard operations. The LS-68 Series also offers a lightweight, low-power portable lunchbox configuration ideal for field-deployable and airborne telemetry processing applications.

The LS-28-DRSM provides 64 GB of solid-state NAND flash per channel, supporting approximately 19 hours of recording at 8 Mbps per channel. The LS-29-R2 RF Recording System offers up to 16 TB of solid-state removable storage operating at 6 GB/sec, suitable for extended RF waveform capture across up to four channels simultaneously.

Lumistar products are designed to comply with IRIG-218, IRIG 106, CCSDS, IEEE 1588 PTP, ARTM Tier II phase noise requirements, ATA Specification 300, and Military Standard C-4150J. The company holds CAGE Code 718V9 and maintains Defense Industrial Base Sector designation, affirming its qualification for defense and federal test range procurement.
